PT06A-22-32P(SR) image
Favorite
PT06A-22-32P(SR) image
Favorite
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description CONN PLUG MALE 32POS SOLDER CUP
PDF
/
Inventory: 8017
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 16 Weeks

Physical

Contact Material Copper Alloy
Mount Cable, Free Hanging
Mounting Type Free Hanging (In-Line)
Shell Material Aluminum
Insert Material Neoprene
Body Material Aluminium
Backshell Material, Plating Aluminum, Olive Drab Cadmium

Technical

Operating Temperature -55°C~125°C
Packaging Bulk
Series MIL-DTL-26482 Series I, PT
Feature Backshell, Cable Clamp, Coupling Nut
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder Cup
Connector Type Plug, Male Pins
Number of Positions 32
Color Olive Drab
Applications Aerospace, Industrial, Instrumentation, Mass Transit, Military
Gender Male
Fastening Type Bayonet Lock
Contact Finish - Mating Gold
Orientation N (Normal)
Shielding Unshielded
Current Rating 7.5A
Military Standard MIL-C-26482
Shell Finish Olive Drab Chromate over Cadmium
Shell Size - Insert 22-32
Contact Style Pin
Body Plating Cadmium

Compliance

Radiation Hardening No
REACH SVHC No SVHC
RoHS Status Non-RoHS Compliant
