PT03E-18-32S image
Favorite
PT03E-18-32S image
Favorite
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description Conn MIL-C-26482 Circular SKT 32 POS Solder ST Jam Nut 32Terminal 1Port
PDF
/
Inventory: 4969
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 16 Weeks

Physical

Contact Material Copper Alloy
Contact Plating Gold
Mount Flanges, Panel
Mounting Type Panel Mount
Mounting Feature Flange
Shell Material Aluminum
Insert Material Neoprene

Technical

Operating Temperature -55°C~125°C
Packaging Bulk
Series MIL-DTL-26482 Series I, PT
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder Cup
Connector Type Receptacle, Female Sockets
Number of Positions 32
Max Operating Temperature 125°C
Min Operating Temperature -55°C
Color Olive Drab
Applications Aerospace, Industrial, Instrumentation, Mass Transit, Military
Fastening Type Bayonet Lock
Contact Finish - Mating Gold
Orientation N (Normal)
Shielding Unshielded
Ingress Protection Environment Sealed
Current Rating 7.5A
Shell Finish Olive Drab Chromate over Cadmium
Shell Size - Insert 18-32

Compliance

RoHS Status Non-RoHS Compliant
Ratings Environment Resistant
