PT02A-14-18PX
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
Conn Miniature Cylindrical PIN 18 POS Solder ST Box Mount 18 Terminal 1 Port
PDF
/
Inventory: 1971
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Contact Material Copper Alloy
Mounting Type Panel Mount
Mounting Feature Flange
Shell Material Aluminum
Insert Material Neoprene
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Published 2006
Series MIL-DTL-26482 Series I, PT
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder Cup
Connector Type Receptacle, Male Pins
Number of Positions 18
Color Olive Drab
Applications Aerospace, Industrial, Instrumentation, Mass Transit, Military
Fastening Type Bayonet Lock
Contact Finish - Mating Gold
Orientation X
Shielding Unshielded
Shell Finish Olive Drab Chromate over Cadmium
Shell Size - Insert 14-18
Compliance
RoHS Status Non-RoHS Compliant
