PT02A-14-18P(002)
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
Circular Connector
PDF
/
Inventory: 8983
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Contact Material Copper Alloy
Contact Plating Gold
Mount Box, Flanges, Panel
Mounting Type Panel Mount
Mounting Feature Flange
Shell Material Aluminum
Insert Material Neoprene
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Published 2006
Series MIL-DTL-26482 Series I, PT
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder Cup
Connector Type Receptacle, Male Pins
Number of Positions 18
Max Operating Temperature 125°C
Min Operating Temperature -55°C
Color Black
Applications Aerospace, Industrial, Instrumentation, Mass Transit, Military
Fastening Type Bayonet Lock
Contact Finish - Mating Gold
Orientation N (Normal)
Shielding Unshielded
Current Rating 7.5A
Shell Finish Black Anodized
Shell Size - Insert 14-18
Number of Contacts 18
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
