PT00A-20-27S(SR)
RoHS
/
Package Metal
Category Connectors, Interconnects / Circular Connectors
Description
Circular MIL Spec Connector 27P Wall Mt Skt Rcpt Sz 20 Strain Relief
PDF
/
Inventory: 8657
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Contact Material Copper Alloy
Mount Flanges, Panel, Wall
Mounting Type Panel Mount
Package / Case Metal
Mounting Feature Flange
Shell Material Aluminum
Insert Material Neoprene
Backshell Material, Plating Aluminum, Olive Drab Cadmium
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Published 2004
Series MIL-DTL-26482 Series I, PT
Feature Backshell, Cable Clamp
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder Cup
Connector Type Receptacle, Female Sockets
Number of Positions 27
Color Olive Drab
Applications Aerospace, Industrial, Instrumentation, Mass Transit, Military
Fastening Type Bayonet Lock
Contact Finish - Mating Gold
Orientation N (Normal)
Shielding Unshielded
Current Rating 7.5A
Military Standard MIL-DTL-26482
Shell Finish Olive Drab Chromate over Cadmium
Shell Size - Insert 20-27
Voltage - Rated AC 600V
Approval Agency UL
Contact Gender Female
Contact Style Socket
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
