PC07E-10-6P
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
POLARIZED Circular Connector
PDF
/
Inventory: 4945
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Contact Material Copper Alloy
Mount Bulkhead, Front Side Nut, Jam Nut, Panel
Mounting Type Panel Mount
Mounting Feature Bulkhead - Front Side Nut
Shell Material Aluminum
Insert Material Neoprene
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Published 2016
Series MIL-DTL-26482 Series I, PC
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder Cup
Connector Type Receptacle, Male Pins
Number of Positions 6
Gender Male
Additional Feature POLARIZED
Fastening Type Threaded
Contact Finish - Mating Gold
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Total Number of Contacts 6
Orientation N (Normal)
Shielding Unshielded
Ingress Protection Environment Resistant
Current Rating 7.5A
Shell Finish Clear Chromate over Bright Cadmium
Shell Size - Insert 10-6
Mating Information MULTIPLE MATING PARTS AVAILABLE
Empty Shell NO
Backshell Type SOLID
Contact Style Pin
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
Ratings Environment Resistant
