MS3126P14-12S
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
CONNECTOR, CIRCULAR, SIZE 14, 12WAY
PDF
/
Buying Options
Total Price: USD $147.39
Unit Price: USD $147.386464
≥1 USD $147.386464
≥10 USD $139.043836
≥100 USD $131.173427
≥500 USD $123.748513
≥1000 USD $116.743879
Inventory: 4180
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
REACH SVHC No SVHC
Radiation Hardening No
Technical
Environmental Characteristics CORROSION RESISTANT
Contact Style Socket
Backshell Type SOLID
Empty Shell NO
Mating Information MULTIPLE MATING PARTS AVAILABLE
Shell Size - Insert 14-12
Shell Finish Olive Drab Chromate over Cadmium
Current Rating 13A
Shielding Unshielded
Orientation N (Normal)
Total Number of Contacts 12
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Contact Finish - Mating Gold
Fastening Type Bayonet Lock
HTS Code 8536.69.40.20
Additional Feature STANDARD: MIL-C-26482, COMPATIBLE CONTACTS: M39029/32-247; M39029/32-259, POLARIZATION AVAILABLE
Gender Receptacle
Applications Aerospace, Communication Systems, Industrial, Instrumentation, Mass Transit, Military
Color Olive Drab
Number of Positions 12
Connector Type Plug, Female Sockets
ECCN Code EAR99
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Coupling Nut, Potted
Series Military, MIL-DTL-26482 Series I, PT
Published 2006
Packaging Bulk
Operating Temperature -55°C~125°C
Physical
Body Material Aluminium
Insert Material Neoprene
Shell Material Aluminum
Mounting Type Free Hanging (In-Line)
Mount Cable, Free Hanging
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 16 Weeks
