MS3108E14S-7S
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
Olive Drab Chromate over Cadmium MIL-5015Type Non-RoHS Compliant Environment Resistant Circular Connector -55C~125C 52.42mm
PDF
/
Buying Options
Total Price: USD $38.62
Unit Price: USD $38.6232
≥1 USD $38.6232
≥10 USD $35.43936
≥100 USD $34.076416
≥500 USD $32.940688
≥1000 USD $31.123312
≥3000 USD $30.214589
Inventory: 77
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Contact Material Copper Alloy
Contact Plating Silver, Gold
Mount Cable, Free Hanging
Mounting Type Free Hanging (In-Line), Right Angle
Shell Material Aluminum Alloy
Insert Material Neoprene
Body Material Aluminium
Backshell Material, Plating Aluminum Alloy, Olive Drab Chromate over Cadmium
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Published 2005
Series MIL-5015 Type
Feature Cable Clamp, Coupling Nut
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder Cup
ECCN Code EAR99
Connector Type Plug, Female Sockets
Number of Positions 3
Color Olive Drab
Applications Marine, Military
Additional Feature STANDARD: MIL-C-5015, COMPATIBLE CONTACTS: 10-597107-161; 10-597107-171
Fastening Type Threaded
Contact Finish - Mating Silver
MIL Conformance YES
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Total Number of Contacts 3
Orientation N (Normal)
Shielding Unshielded
Ingress Protection Environment Resistant
Military Standard MIL-DTL-5015
Shell Finish Olive Drab Chromate over Cadmium
Shell Size - Insert 14S-7
Contact Gender Female
Empty Shell NO
Backshell Type SOLID
Contact Style Socket
Plating Cadmium, Chromate
Body Plating Cadmium
Dimensions
Length 52.42mm
Compliance
Radiation Hardening No
REACH SVHC Unknown
RoHS Status Non-RoHS Compliant
Ratings Environment Resistant
