MS3106A18-15S
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
STANDARD: MIL-C-5015COMPATIBLE CONTACT: 10-597107-131 Circular Connector
PDF
/
Inventory: 4445
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Radiation Hardening No
Dimensions
Length 49.22mm
Technical
Plating Cadmium, Chromate
Contact Style Socket
Backshell Type SOLID
Empty Shell NO
Shell Size - Insert 18-15
Shell Finish Olive Drab Chromate over Cadmium
Shielding Unshielded
Orientation N (Normal)
Total Number of Contacts 4
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Contact Finish - Mating Silver
Fastening Type Threaded
Additional Feature STANDARD: MIL-C-5015, COMPATIBLE CONTACT: 10-597107-131
Gender Female
Applications Marine, Military
Color Olive Drab
Number of Positions 4
Connector Type Plug, Female Sockets
ECCN Code EAR99
Termination Solder Cup
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Backshell, Coupling Nut
Series MIL-5015 Type
Published 2002
Packaging Bulk
Operating Temperature -55°C~125°C
Physical
Backshell Material, Plating Aluminum Alloy, Olive Drab Chromate over Cadmium
Insert Material Neoprene
Shell Material Aluminum Alloy
Mounting Type Free Hanging (In-Line)
Mount Cable, Free Hanging
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 16 Weeks
