MS3102R20-32P image
Favorite
MS3102R20-32P image
Favorite
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description Conn MIL-DTL-5015 Circular PIN 8 POS Solder ST Box Mount 8 Terminal 1 Port
PDF
/
Inventory: 6506
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 16 Weeks

Physical

Contact Material Copper Alloy
Contact Plating Silver
Mount Flanges, Panel
Mounting Type Panel Mount
Mounting Feature Flange
Shell Material Aluminum Alloy
Insert Material Neoprene

Technical

Operating Temperature -55°C~125°C
Packaging Bulk
Published 2005
Series Military, MIL-DTL-5015
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder Cup
Connector Type Receptacle, Male Pins
Number of Positions 8
Max Operating Temperature 125°C
Min Operating Temperature -55°C
Color Olive Drab
Applications Marine, Military
Gender Female
Fastening Type Threaded
Contact Finish - Mating Silver
Orientation N (Normal)
Shielding Unshielded
Ingress Protection Environment Resistant
Depth 38.1mm
Shell Finish Olive Drab Chromate over Cadmium
Shell Size - Insert 20-32
Plating Cadmium, Chromate
Cable Opening 1.125 (28.58mm)

Dimensions

Length 38.91mm

Compliance

RoHS Status Non-RoHS Compliant
Ratings Environment Resistant
