MS3102R20-2P
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
Circular Connector
PDF
/
Buying Options
Total Price: USD $63.02
Unit Price: USD $63.017606
≥1 USD $63.017606
≥10 USD $59.450571
≥100 USD $56.085445
≥500 USD $52.910802
≥1000 USD $49.915844
Inventory: 968
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Contact Material Copper Alloy
Mount Box, Flanges, Panel
Mounting Type Panel Mount
Mounting Feature Flange
Shell Material Aluminum Alloy
Insert Material Neoprene
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Published 2005
Series Military, MIL-DTL-5015
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder Cup
ECCN Code EAR99
Connector Type Receptacle, Male Pins
Number of Positions 1
Color Olive Drab
Applications Marine, Military
Gender Female
HTS Code 8536.69.40.20
Fastening Type Threaded
Contact Finish - Mating Silver
MIL Conformance YES
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Total Number of Contacts 1
Orientation N (Normal)
Shielding Unshielded
Ingress Protection Environment Resistant
Depth 38.1mm
Shell Finish Olive Drab Chromate over Cadmium
Shell Size - Insert 20-2
Empty Shell NO
Backshell Type SOLID
Plating Cadmium, Chromate
Cable Opening 1.125 (28.58mm)
Dimensions
Length 38.91mm
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
Ratings Environment Resistant
