MS3102A28-10S
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
CONN RCPT FMALE 7POS SOLDER CUP
PDF
/
Buying Options
Total Price: USD $111.04
Unit Price: USD $111.0384
≥1 USD $111.0384
Inventory: 46
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Length 38.88mm
Technical
Cable Opening 1.625 (41.28mm)
Plating Cadmium, Chromate
Environmental Characteristics ENVIRONMENT RESISTANT
Backshell Type SOLID
Empty Shell NO
Contact Gender Female
Shell Size - Insert 28-10
Shell Finish Olive Drab Chromate over Cadmium
Military Standard MIL-DTL-5015
Depth 50.8mm
Shielding Unshielded
Orientation N (Normal)
Total Number of Contacts 7
Option GENERAL PURPOSE
Mixed Contacts YES
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Contact Finish - Mating Silver
Fastening Type Threaded
HTS Code 8536.69.40.20
Additional Feature STANDARD:MIL-C-5015, POLARIZATION AVAILABLE
Applications Marine, Military
Color Olive Drab
Number of Positions 7
Connector Type Receptacle, Female Sockets
ECCN Code EAR99
Termination Solder Cup
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series MIL-5015 Type
Published 2005
Packaging Bulk
Operating Temperature -55°C~125°C
Physical
Insert Material Neoprene
Shell Material Aluminum Alloy
Mounting Feature Flange
Mounting Type Panel Mount
Mount Box, Flanges, Panel
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 16 Weeks
