MS3101E24-28S image
Favorite
MS3101E24-28S image
Favorite
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description Circular MIL Spec Connector 24P #16 SKT CONTACTS
PDF
/
Buying Options
Total Price: USD $128.97
Unit Price: USD $128.9728
≥1 USD $128.9728
≥10 USD $111.7776
≥100 USD $98.6304
≥500 USD $88.2464
≥1000 USD $77.3872
Inventory: 86
Minimum: 1
-
+

Technical Details

Technical

Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Contact Finish - Mating Silver
Fastening Type Threaded
Voltage - Rated 250V
Applications Marine, Military
Color Olive Drab
Number of Positions 24
Connector Type Receptacle, Female Sockets
Termination Solder Cup
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Cable Clamp
JESD-609 Code e4
Series MIL-5015 Type
Published 2005
Packaging Bulk
Operating Temperature -55°C~125°C
Cable Opening 0.781 (19.84mm)
Body Plating Cadmium
Wire Gauge (Min) 16 AWG
Wire Gauge (Max) 20 AWG
Plating Cadmium, Chromate
Body/Shell Style PLUG
Contact Style Socket
Backshell Type SOLID
Empty Shell NO
Contact Gender Female
Mating Information MULTIPLE MATING PARTS AVAILABLE
Shell Size - Insert 24-28
Shell Finish Olive Drab Chromate over Cadmium
Military Standard MIL-DTL-5015
Current Rating 13A
Depth 45.23mm
Ingress Protection Environment Resistant
Shielding Unshielded
Orientation N (Normal)
Total Number of Contacts 24

Physical

Backshell Material, Plating Aluminum Alloy, Olive Drab Chromate over Cadmium
Body Material Aluminium
Insert Material Neoprene
Shell Material Aluminum Alloy
Mounting Type Free Hanging (In-Line)
Mount Cable, Free Hanging
Contact Material Copper Alloy

Supply Chain

Factory Lead Time 16 Weeks

Compliance

Ratings Environment Resistant
RoHS Status Non-RoHS Compliant
REACH SVHC No SVHC
Radiation Hardening No

Dimensions

Length 73.27mm
