MS3101A22-27S
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
Conn MIL-DTL-5015 Circular SKT 9 POS Solder ST Cable Mount 9 Terminal 1 Port
PDF
/
Buying Options
Total Price: USD $37.03
Unit Price: USD $37.03233
≥1 USD $37.03233
≥10 USD $34.936166
≥100 USD $32.958644
≥500 USD $31.093063
≥1000 USD $29.333082
Inventory: 6415
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Radiation Hardening No
Dimensions
Length 49.22mm
Technical
Plating Cadmium, Chromate
Environmental Characteristics ENVIRONMENT RESISTANT
Contact Style Socket
Backshell Type SOLID
Empty Shell NO
Shell Size - Insert 22-27
Shell Finish Olive Drab Chromate over Cadmium
Shielding Unshielded
Orientation N (Normal)
Total Number of Contacts 9
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Contact Finish - Mating Silver
Fastening Type Threaded
Additional Feature STANDARD:MIL-C-5015, POLARIZATION AVAILABLE
Gender Female
Applications Marine, Military
Color Olive Drab
Number of Positions 9
Connector Type Receptacle, Female Sockets
Termination Solder Cup
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Backshell
Series MIL-5015 Type
Packaging Bulk
Operating Temperature -55°C~125°C
Physical
Backshell Material, Plating Aluminum Alloy, Olive Drab Chromate over Cadmium
Insert Material Neoprene
Shell Material Aluminum Alloy
Mounting Type Free Hanging (In-Line)
Mount Cable, Free Hanging
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 16 Weeks
