MS3101A20-18P
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
AMPHENOL MS3101A20-18P Circular Connector, MIL-DTL-5015 Series, Cable Mount Receptacle, 9, Solder Pin, Threaded, 20-18
PDF
/
Buying Options
Total Price: USD $28.75
Unit Price: USD $28.749137
≥1 USD $28.749137
≥10 USD $27.121824
≥100 USD $25.586625
≥500 USD $24.138334
≥1000 USD $22.77201
Inventory: 3385
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
REACH SVHC No SVHC
Radiation Hardening No
Technical
Body Plating Cadmium
Environmental Characteristics ENVIRONMENT RESISTANT
Contact Style Pin
Backshell Type SOLID
Empty Shell NO
Shell Size - Insert 20-18
Shell Finish Olive Drab Chromate over Cadmium
Military Standard MIL-DTL-5015
Shielding Unshielded
Orientation N (Normal)
Total Number of Contacts 9
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Contact Finish - Mating Silver
Fastening Type Threaded
Additional Feature STANDARD:MIL-C-5015, POLARIZATION AVAILABLE
Gender Receptacle
Applications Marine, Military
Color Olive Drab
Number of Positions 9
Connector Type Receptacle, Male Pins
Termination Solder Cup
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Backshell
Series MIL-5015 Type
Published 2005
Packaging Bulk
Operating Temperature -55°C~125°C
Physical
Backshell Material, Plating Aluminum Alloy, Olive Drab Chromate over Cadmium
Body Material Aluminium
Insert Material Neoprene
Shell Material Aluminum Alloy
Mounting Type Free Hanging (In-Line)
Mount Cable, Free Hanging
Contact Plating Silver, Gold
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 16 Weeks
