MS3100A18-19P
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
AMPHENOL MS3100A18-19P Circular Connector, MIL-DTL-5015 Series, Wall Mount Receptacle, 10, Solder Pin, Threaded, 18-19
PDF
/
Buying Options
Total Price: USD $33.31
Unit Price: USD $33.314986
≥1 USD $33.314986
≥10 USD $31.429232
≥100 USD $29.650223
≥500 USD $27.971905
≥1000 USD $26.388593
Inventory: 8161
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Contact Material Copper Alloy
Contact Plating Silver, Gold
Mount Flanges, Panel, Wall
Mounting Type Panel Mount
Mounting Feature Flange
Shell Material Aluminum Alloy
Insert Material Neoprene
Body Material Aluminium
Backshell Material, Plating Aluminum Alloy, Olive Drab Chromate over Cadmium
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Published 2005
Series MIL-5015 Type
Feature Backshell
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder Cup
ECCN Code EAR99
Connector Type Receptacle, Male Pins
Number of Positions 10
Color Olive Drab
Applications Marine, Military
Gender Receptacle
Additional Feature STANDARD:MIL-C-5015, POLARIZATION AVAILABLE
HTS Code 8536.69.40.20
Fastening Type Threaded
Contact Finish - Mating Silver
MIL Conformance YES
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Total Number of Contacts 10
Orientation N (Normal)
Shielding Unshielded
Military Standard MIL-DTL-5015
Shell Finish Olive Drab Chromate over Cadmium
Shell Size - Insert 18-19
Contact Gender Male
Empty Shell NO
Backshell Type SOLID
Contact Style Pin
Environmental Characteristics ENVIRONMENT RESISTANT
Plating Cadmium, Chromate
Body Plating Cadmium
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status Non-RoHS Compliant
