MS17344R28N20P
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
Conn MIL-C-22992 Circular PIN 14 POS Solder ST Cable Mount 14 Terminal 1 Port
PDF
/
Inventory: 9937
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Contact Material Copper Alloy
Mount Cable, Free Hanging
Mounting Type Free Hanging (In-Line)
Shell Material Aluminum
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Published 2003
Series Military, MIL-DTL-22992
Feature Coupling Nut
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder Cup
Connector Type Plug, Male Pins
Number of Positions 14
Applications Military
Additional Feature STANDARD: MIL-C-22992, COMPATIBLE CONTACTS: 10-36982-3; 10-36982-5
Fastening Type Threaded
Contact Finish - Mating Silver
MIL Conformance YES
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Total Number of Contacts 14
Orientation N (Normal)
Shielding Unshielded
Ingress Protection Waterproof
Shell Finish Anodic Coating (Alumilite)
Shell Size - Insert 28-20
Empty Shell NO
Backshell Type SOLID
Environmental Characteristics CORROSION RESISTANT
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
