GTC06F-16-10S
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
AMPHENOL GTC06F16-10S Circular Connector, GT Series, MIL-DTL-5015 Series Equivalent, Straight Plug, 3 Contacts
PDF
/
Inventory: 5184
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Contact Material Copper Alloy
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Shell Material Aluminum
Insert Material Neoprene
Body Material Aluminium
Backshell Material, Plating Aluminum, Olive Drab Cadmium
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Published 2015
Series GT, MIL-5015 Derivative
Feature Backshell, Cable Clamp, Coupling Nut
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
Connector Type Plug, Female Sockets
Number of Positions 3
Color Olive Drab
Applications Aerospace, Marine, Mass Transit, Military
Gender Male
Fastening Type Reverse Bayonet Lock
Contact Finish - Mating Silver
Orientation N (Normal)
Shielding Unshielded
Ingress Protection IP67 - Dust Tight, Waterproof
Reach Compliance Code unknown
Shell Finish Olive Drab Cadmium
Shell Size - Insert 16-10
Contact Style Socket
Body Plating Cadmium
Dimensions
Length 70mm
Compliance
REACH SVHC No SVHC
RoHS Status Non-RoHS Compliant
Ratings Dust Tight, IP67, Waterproof
