CS3106A-32-76P
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
Circular Connector
PDF
/
Inventory: 5774
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Contact Material Copper Alloy
Contact Plating Silver
Mount Cable, Free Hanging
Mounting Type Free Hanging (In-Line)
Shell Material Aluminum Alloy
Insert Material Neoprene
Backshell Material, Plating Aluminum Alloy, Olive Drab Chromate over Cadmium
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Published 2005
Series CS, MIL-5015 Derivative
Feature Backshell, Coupling Nut
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder Cup
Connector Type Plug, Male Pins
Number of Positions 19
Max Operating Temperature 125°C
Min Operating Temperature -55°C
Color Olive Drab
Applications Marine, Military
Gender Male
Fastening Type Threaded
Contact Finish - Mating Silver
Orientation N (Normal)
Shielding Unshielded
Shell Finish Olive Drab Chromate over Cadmium
Shell Size - Insert 32-76
Number of Contacts 19
Plating Cadmium, Chromate
Dimensions
Length 54.81mm
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
Ratings Environment Resistant
