RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description Circular Connector
PDF
/
Inventory: 4168
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Ratings Environment Resistant
RoHS Status Non-RoHS Compliant
Radiation Hardening No

Technical

Number of Contacts 16
Shell Size - Insert 24-64
Shell Finish Olive Drab Chromate over Cadmium
Shielding Unshielded
Orientation N (Normal)
Contact Finish - Mating Silver
Fastening Type Threaded
Gender Male
Applications Marine, Military
Color Olive Drab
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Number of Positions 16
Connector Type Plug, Male Pins
Termination Solder Cup
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Backshell, Coupling Nut
Series CS, MIL-5015 Derivative
Published 2015
Packaging Bulk
Operating Temperature -55°C~125°C

Physical

Backshell Material, Plating Aluminum Alloy, Olive Drab Chromate over Cadmium
Insert Material Neoprene
Shell Material Aluminum Alloy
Mounting Type Free Hanging (In-Line)
Mount Cable, Free Hanging
Contact Plating Silver
Contact Material Constantan, Iron

Supply Chain

Factory Lead Time 16 Weeks
