CS3101A-14S-78P
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
Conn MIL-DTL-5015 Circular PIN 2 POS Solder ST Cable Mount 2 Terminal 1 Port
PDF
/
Inventory: 4971
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings Environment Resistant
RoHS Status Non-RoHS Compliant
Radiation Hardening No
Technical
Number of Contacts 2
Shell Size - Insert 14S-78
Shell Finish Olive Drab Chromate over Cadmium
Shielding Unshielded
Orientation N (Normal)
Contact Finish - Mating Silver
Fastening Type Threaded
Gender Male
Applications Marine, Military
Color Olive Drab
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Number of Positions 2
Connector Type Receptacle, Male Pins
Termination Solder Cup
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Backshell
Series CS, MIL-5015 Derivative
Published 2005
Packaging Bulk
Operating Temperature -55°C~125°C
Physical
Backshell Material, Plating Aluminum Alloy, Olive Drab Chromate over Cadmium
Insert Material Neoprene
Shell Material Aluminum Alloy
Number of Pins 2
Mounting Type Free Hanging (In-Line)
Mount Cable, Free Hanging
Contact Plating Silver
Contact Material Alumel, Chromel
Supply Chain
Factory Lead Time 16 Weeks
