ACC06E22-22P-003 image
Favorite
ACC06E22-22P-003 image
Favorite
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description AMPHENOL ACC06E22-22P-003 Circular Connector, AC Series, MIL-DTL-5015 Series Equivalent, Straight Plug, 4, Crimp Pin
PDF
/
Buying Options
Total Price: USD $57.93
Unit Price: USD $57.934466
≥1 USD $57.934466
≥10 USD $54.655157
≥100 USD $51.561469
≥500 USD $48.642898
≥1000 USD $45.889523
Inventory: 7305
Minimum: 1
-
+

Technical Details

Physical

Contact Material Copper Alloy
Contact Plating Silver
Mounting Type Free Hanging (In-Line)
Shell Material Aluminum
Body Material Aluminium
Backshell Material, Plating Aluminum, Olive Drab Cadmium

Technical

Operating Temperature -55°C~125°C
Packaging Bulk
Published 2005
Series AC, MIL-5015 Derivative
Feature Backshell, Cable Clamp, Coupling Nut
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
Connector Type Plug, Male Pins
Number of Positions 4
Color Olive Drab
Applications Automotive, Industrial
Gender Male
Fastening Type Threaded
Contact Finish - Mating Silver
Orientation N (Normal)
Shielding Unshielded
Ingress Protection Environment Resistant
Shell Finish Olive Drab Cadmium
Shell Size - Insert 22-22
Number of Contacts 4
Body Plating Cadmium
Cable Opening 0.750 (19.05mm)

Compliance

REACH SVHC No SVHC
RoHS Status Non-RoHS Compliant
