ACA3100E16-9PBF80
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
STANDARD: MIL-C-5015CAMPATIBLE CONTACTS: ACA-108388; ACA-108295 Circular Connector
PDF
/
Buying Options
Total Price: USD $30.48
Unit Price: USD $30.484369
≥1 USD $30.484369
≥10 USD $28.758834
≥100 USD $27.130979
≥500 USD $25.595263
≥1000 USD $24.14647
Inventory: 5094
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Radiation Hardening No
Technical
Environmental Characteristics CORROSION RESISTANT
Backshell Type SOLID
Empty Shell NO
Mating Information MULTIPLE MATING PARTS AVAILABLE
Shell Size - Insert 16-9
Shell Finish Olive Drab Cadmium
Ingress Protection IP67 - Dust Tight, Waterproof
Shielding Unshielded
Orientation N (Normal)
Total Number of Contacts 4
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Contact Finish - Mating Silver
Fastening Type Reverse Bayonet Lock
Additional Feature STANDARD: MIL-C-5015, CAMPATIBLE CONTACTS: ACA-108388; ACA-108295
Applications Automation, Industrial, Instrumentation, Testing Equipment
Color Olive Drab
Number of Positions 4
Connector Type Receptacle, Male Pins
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Backshell, Cable Clamp
Series ACA-B, MIL-5015 Derivative
Packaging Bulk
Operating Temperature -55°C~125°C
Physical
Backshell Material, Plating Aluminum Alloy, Olive Drab Cadmium
Insert Material Polychloroprene
Shell Material Aluminum Alloy
Mounting Feature Flange
Mounting Type Panel Mount
Mount Wall
Contact Material Copper Alloy
