97-3108B22-5P image
Favorite
97-3108B22-5P image
Favorite
RoHS
/
Package Metal
Category Connectors, Interconnects / Circular Connectors
Description Circular Connector
PDF
/
Inventory: 6499
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status Non-RoHS Compliant
REACH SVHC No SVHC
Radiation Hardening No

Technical

Plating Cadmium, Chromate
Contact Style Pin
Contact Gender Male
Approval Agency CSA, UL
Shell Size - Insert 22-5
Shell Finish Olive Drab Chromate over Cadmium
Military Standard MIL-DTL-5015
Shielding Unshielded
Orientation N (Normal)
Contact Finish - Mating Silver
Voltage - Rated DC 1.25kV
Fastening Type Threaded
Applications Automotive, Industrial
Color Olive Drab
Number of Positions 6
Connector Type Plug, Male Pins
Termination Solder Cup
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Coupling Nut
Series 97
Published 2005
Packaging Bulk
Operating Temperature -55°C~125°C

Physical

Backshell Material, Plating Aluminum Alloy, Olive Drab Chromate over Cadmium
Body Material Aluminium
Insert Material Diallyl Phthalate (DAP)
Shell Material Aluminum Alloy
Package / Case Metal
Mounting Type Free Hanging (In-Line), Right Angle
Mount Cable, Free Hanging
Contact Material Copper Alloy
