97-3106B22-10PX
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
STANDARD: MIL-C-5015 Circular Connector
PDF
/
Inventory: 8762
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Copper Alloy
Mounting Type Free Hanging (In-Line)
Number of Pins 16
Shell Material Aluminum Alloy
Insert Material Diallyl Phthalate (DAP)
Backshell Material, Plating Aluminum Alloy, Olive Drab Chromate over Cadmium
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Published 2006
Series 97
Feature Backshell, Coupling Nut
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder Cup
Connector Type Plug, Male Pins
Number of Positions 4
Color Olive Drab
Applications Automotive, Industrial
Gender Male
Additional Feature STANDARD: MIL-C-5015
Fastening Type Threaded
Contact Finish - Mating Silver
MIL Conformance YES
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Total Number of Contacts 4
Orientation X
Shielding Unshielded
Reach Compliance Code unknown
Shell Finish Olive Drab Chromate over Cadmium
Shell Size - Insert 22-10
Mating Information MULTIPLE MATING PARTS AVAILABLE
Empty Shell NO
Backshell Type SPLIT
Contact Style Pin
Environmental Characteristics ENVIRONMENT RESISTANT
Compliance
RoHS Status Non-RoHS Compliant
