97-3106A28-15PX
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
AMPHENOL 97-3106A28-15PX Circular Connector, 97 Series, MIL-DTL-5015 Series Equivalent, Straight Plug, 35, Solder Pin
PDF
/
Buying Options
Total Price: USD $87.17
Unit Price: USD $87.1728
≥1 USD $87.1728
≥10 USD $75.548
≥100 USD $66.66
≥500 USD $59.6464
≥1000 USD $52.2984
Inventory: 27
Minimum: 1
-
+
Technical Details
Physical
Contact Material Copper Alloy
Mount Cable
Mounting Type Free Hanging (In-Line)
Shell Material Aluminum Alloy
Insert Material Diallyl Phthalate (DAP)
Body Material Aluminium
Backshell Material, Plating Aluminum Alloy, Olive Drab Chromate over Cadmium
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Published 2005
Series 97
Feature Backshell, Coupling Nut
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder Cup
Connector Type Plug, Male Pins
Number of Positions 35
Color Olive Drab
Applications Automotive, Industrial
Gender Male
Fastening Type Threaded
Contact Finish - Mating Silver
Orientation X
Shielding Unshielded
Military Standard MIL-DTL-5015
Shell Finish Olive Drab Chromate over Cadmium
Shell Size - Insert 28-15
Contact Style Pin
Body Plating Cadmium
Dimensions
Length 57.15mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status Non-RoHS Compliant
