97-3102A16S-4PY
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
STANDARD: MIL-C-5015 Circular Connector
PDF
/
Inventory: 9488
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
DIN Conformance NO
MIL Conformance YES
Contact Finish - Mating Silver
Fastening Type Threaded
Additional Feature STANDARD: MIL-C-5015
Gender Male
Applications Automotive, Industrial
Color Olive Drab
Number of Positions 2
Connector Type Receptacle, Male Pins
Termination Solder Cup
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series 97
Published 2006
Packaging Bulk
Operating Temperature -55°C~125°C
Environmental Characteristics ENVIRONMENT RESISTANT
Contact Style Pin
Backshell Type SOLID
Empty Shell NO
Mating Information MULTIPLE MATING PARTS AVAILABLE
Shell Size - Insert 16S-4
Shell Finish Olive Drab Chromate over Cadmium
Shielding Unshielded
Orientation Y
Total Number of Contacts 2
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
Physical
Insert Material Diallyl Phthalate (DAP)
Shell Material Aluminum Alloy
Mounting Feature Flange
Mounting Type Panel Mount
Mount Box
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 2 Weeks
Compliance
RoHS Status Non-RoHS Compliant
Radiation Hardening No
