TVS07RK-23-35SA
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
Passivated MIL-DTL-38999Series III Tri-Start? TV ROHS3Compliant Environment Resistant Circular Connector -65C~200C 50.0muin 1.27mum
PDF
/
Buying Options
Total Price: USD $798.78
Unit Price: USD $798.7848
≥1 USD $798.7848
≥10 USD $698.94
≥100 USD $621.3328
≥500 USD $446.9432
Inventory: 91
Minimum: 1
-
+
Technical Details
Technical
Contact Finish - Mating Gold
MIL Conformance YES
DIN Conformance NO
IEC Conformance NO
Filter Feature YES
Mixed Contacts NO
Total Number of Contacts 100
Orientation A
Shielding Shielded
Ingress Protection Environment Resistant
Shell Finish Passivated
Shell Size - Insert 23-35
Empty Shell YES
Backshell Type SOLID
Fastening Type Threaded
HTS Code 8536.69.40.20
Gender Female
Applications Aviation, Marine, Military
Number of Positions 100
Connector Type Receptacle, Female Sockets
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Firewall Usage
Series MIL-DTL-38999 Series III, Tri-Start? TV
Published 2006
Packaging Bulk
Operating Temperature -65°C~200°C
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Ratings Environment Resistant
Physical
Insert Material Thermoplastic
Shell Material Stainless Steel
Mounting Feature Bulkhead - Front Side Nut
Mounting Type Panel Mount
Mount Bulkhead, Front Side Nut, Jam Nut, Panel
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 12 Weeks
