TVS07RK-15-18P
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
Passivated MIL-DTL-38999Series III Tri-Start? TV ROHS3Compliant Environment Resistant Circular Connector -65C~200C 50.0muin 1.27mum
PDF
/
Buying Options
Total Price: USD $783.82
Unit Price: USD $783.816
≥1 USD $783.816
≥10 USD $685.8456
≥100 USD $609.6552
≥500 USD $438.636
Inventory: 152
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Contact Material Copper Alloy
Mount Bulkhead, Front Side Nut, Panel
Mounting Type Panel Mount
Mounting Feature Bulkhead - Front Side Nut
Shell Material Stainless Steel
Insert Material Thermoplastic
Technical
Operating Temperature -65°C~200°C
Packaging Bulk
Published 2006
Series MIL-DTL-38999 Series III, Tri-Start? TV
Feature Firewall Usage
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
Connector Type Receptacle, Male Pins
Number of Positions 18
Applications Aviation, Marine, Military
Additional Feature EMI SHIELD; TRI-START, STANDARD: MIL-DTL-38999
Fastening Type Threaded
Contact Finish - Mating Gold
MIL Conformance YES
DIN Conformance NO
IEC Conformance NO
Filter Feature YES
Mixed Contacts NO
Option GENERAL PURPOSE
Total Number of Contacts 18
Orientation N (Normal)
Shielding Shielded
Ingress Protection Environment Resistant
Reach Compliance Code unknown
Shell Finish Passivated
Shell Size - Insert 15-18
Empty Shell YES
Backshell Type SOLID
Environmental Characteristics CORROSION RESISTANT
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Compliance
RoHS Status ROHS3 Compliant
Ratings Environment Resistant
