TVS07RF-25-37SA
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
Conn MIL-DTL-38999 Circular SKT 37 POS Crimp ST Jam Nut 37 Terminal 1 Port
PDF
/
Buying Options
Total Price: USD $263.65
Unit Price: USD $263.652329
≥1 USD $263.652329
≥10 USD $248.728618
≥100 USD $234.649632
≥500 USD $221.367581
≥1000 USD $208.837341
Inventory: 4533
Minimum: 1
-
+
Technical Details
Compliance
Ratings Environment Resistant
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Length 31.9mm
Technical
Plating Electroless Nickel
Shell Size - Insert 25-37
Shell Finish Electroless Nickel
Depth 55.58mm
Ingress Protection Environment Resistant
Shielding Shielded
Orientation A
Contact Finish - Mating Gold
Fastening Type Threaded
Gender Female
Applications Aviation, Marine, Military
Color Silver
Number of Positions 37
Connector Type Receptacle, Female Sockets
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series MIL-DTL-38999 Series III, Tri-Start? TV
Published 2011
Packaging Bulk
Operating Temperature -65°C~200°C
Physical
Insert Material Thermoplastic
Shell Material Aluminum
Mounting Feature Bulkhead - Front Side Nut
Mounting Type Panel Mount
Mount Bulkhead, Front Side Nut, Jam Nut, Panel
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 16 Weeks
