TVS07RF-25-11PD
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
Circular MIL Spec Connector 11P Strt Pin Plug Sz 25 Tri-Start III
PDF
/
Inventory: 9074
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Copper Alloy
Mount Bulkhead, Front Side Nut, Jam Nut, Panel
Mounting Type Panel Mount
Mounting Feature Bulkhead - Front Side Nut
Shell Material Aluminum
Insert Material Thermoplastic
Technical
Operating Temperature -65°C~200°C
Packaging Bulk
Series MIL-DTL-38999 Series III, Tri-Start? TV
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
ECCN Code EAR99
Connector Type Receptacle, Male Pins
Number of Positions 11 (2 + 9 Power)
Color Silver
Applications Aviation, Marine, Military
Gender Female
HTS Code 8536.69.40.20
Fastening Type Threaded
Contact Finish - Mating Gold
Orientation D
Shielding Shielded
Ingress Protection Environment Resistant
Military Standard MIL-DTL-38999
Shell Finish Electroless Nickel
Shell Size - Insert 25-11
Number of Contacts 11
Contact Gender Male
Plating Electroless Nickel
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Ratings Environment Resistant
