TVS07RF-25-11PC
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
Conn MIL-DTL-38999 Circular PIN 11 POS Crimp ST Jam Nut 11 Terminal 1 Port
PDF
/
Inventory: 8794
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings Environment Resistant
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Technical
Plating Electroless Nickel
Contact Gender Male
Number of Contacts 11
Shell Size - Insert 25-11
Shell Finish Electroless Nickel
Military Standard MIL-DTL-38999
Ingress Protection Environment Resistant
Shielding Shielded
Orientation C
Contact Finish - Mating Gold
Fastening Type Threaded
HTS Code 8536.69.40.20
Gender Female
Applications Aviation, Marine, Military
Color Silver
Number of Positions 11 (2 + 9 Power)
Connector Type Receptacle, Male Pins
ECCN Code EAR99
Termination Crimp
Part Status Active
Series MIL-DTL-38999 Series III, Tri-Start? TV
Packaging Bulk
Operating Temperature -65°C~200°C
Physical
Insert Material Thermoplastic
Shell Material Aluminum
Mounting Feature Bulkhead - Front Side Nut
Mounting Type Panel Mount
Mount Bulkhead, Front Side Nut, Jam Nut, Panel
Contact Material Copper Alloy
