TVS07RF-21-16S
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
AMPHENOL TVS07RF-21-16S Circular Connector, MIL-C-38999 Series III, Receptacle, 16, Socket, Solder, Panel
PDF
/
Buying Options
Total Price: USD $164.88
Unit Price: USD $164.8768
≥1 USD $164.8768
≥10 USD $142.89088
Inventory: 95
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Contact Material Copper Alloy
Mount Bulkhead, Front Side Nut, Jam Nut, Panel
Mounting Type Panel Mount
Mounting Feature Bulkhead - Front Side Nut
Shell Material Aluminum
Insert Material Thermoplastic
Body Material Aluminium
Technical
Operating Temperature -65°C~200°C
Packaging Bulk
Published 2011
Series MIL-DTL-38999 Series III, Tri-Start? TV
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
ECCN Code EAR99
Connector Type Receptacle, Female Sockets
Number of Positions 16
Color Silver
Applications Aviation, Marine, Military
Gender Receptacle
HTS Code 8536.69.40.20
Fastening Type Threaded
Contact Finish - Mating Gold
MIL Conformance YES
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Total Number of Contacts 16
Orientation N (Normal)
Shielding Shielded
Ingress Protection Environment Resistant
Depth 49.23mm
Shell Finish Electroless Nickel
Shell Size - Insert 21-16
Empty Shell YES
Backshell Type SOLID
Plating Electroless Nickel
Dimensions
Length 31.9mm
Contact Finish Thickness - Mating 50.0μin 1.27μm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Ratings Environment Resistant
