TVS07RF-17-99JN
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
CONN RCPT FMALE 23POS GOLD CRIMP
PDF
/
Buying Options
Total Price: USD $284.46
Unit Price: USD $284.456996
≥1 USD $284.456996
≥10 USD $268.355659
≥100 USD $253.165719
≥500 USD $238.835582
≥1000 USD $225.31659
Inventory: 7141
Minimum: 1
-
+
Technical Details
Physical
Contact Material Copper Alloy
Contact Plating Gold
Mount Bulkhead, Front Side Nut, Panel
Mounting Type Panel Mount
Mounting Feature Bulkhead - Front Side Nut
Number of Pins 23
Shell Material Aluminum
Insert Material Thermoplastic
Technical
Operating Temperature -65°C~200°C
Packaging Bulk
Published 2013
Series MIL-DTL-38999 Series III, Tri-Start? TV
Feature Shielded
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
Connector Type Receptacle, Female Sockets
Number of Positions 23
Max Operating Temperature 200°C
Min Operating Temperature -65°C
Color Silver
Applications Aviation, Marine, Military
Fastening Type Threaded
Contact Finish - Mating Gold
Orientation N (Normal)
Shielding Shielded
Ingress Protection Environment Resistant
Shell Finish Electroless Nickel
Shell Size - Insert 17-99
Dimensions
Contact Finish Thickness - Mating 100.0μin 2.54μm
Compliance
RoHS Status ROHS3 Compliant
Ratings Environment Resistant
