TVS06RF-J90S
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
Electroless Nickel MIL-DTL-38999Series III Tri-Start? TV ROHS3Compliant Environment Resistant Circular Connector 200C 100.0muin 2.54mum
PDF
/
Inventory: 1461
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Copper Alloy
Contact Plating Gold
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Number of Pins 46
Shell Material Aluminum
Insert Material Thermoplastic
Technical
Operating Temperature -65°C~200°C
Packaging Bulk
Published 2012
Series MIL-DTL-38999 Series III, Tri-Start? TV
Feature Coupling Nut, Self Locking
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
Connector Type Plug, Female Sockets
Number of Positions 46 (44 + 2 Twinax)
Max Operating Temperature 200°C
Min Operating Temperature -65°C
Color Silver
Applications Aviation, Marine, Military
Fastening Type Threaded
Contact Finish - Mating Gold
Orientation N (Normal)
Shielding Shielded
Ingress Protection Environment Resistant
Shell Finish Electroless Nickel
Shell Size - Insert 25-90
Dimensions
Contact Finish Thickness - Mating 100.0μin 2.54μm
Compliance
RoHS Status ROHS3 Compliant
Ratings Environment Resistant
