TVS06RF-J8PE
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
Electroless Nickel MIL-DTL-38999Series III Tri-Start? TV ROHS3Compliant Environment Resistant Circular Connector 200C 100.0muin 2.54mum
PDF
/
Inventory: 1962
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings Environment Resistant
RoHS Status ROHS3 Compliant
Dimensions
Contact Finish Thickness - Mating 100.0μin 2.54μm
Technical
Shell Size - Insert 25-8
Shell Finish Electroless Nickel
Ingress Protection Environment Resistant
Shielding Shielded
Orientation E
Contact Finish - Mating Gold
Fastening Type Threaded
Applications Aviation, Marine, Military
Color Silver
Min Operating Temperature -65°C
Max Operating Temperature 200°C
Number of Positions 8 (Twinax)
Connector Type Plug, Male Pins
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Coupling Nut, Self Locking
Series MIL-DTL-38999 Series III, Tri-Start? TV
Published 2012
Packaging Bulk
Operating Temperature -65°C~200°C
Physical
Insert Material Thermoplastic
Shell Material Aluminum
Number of Pins 8
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Plating Gold
Contact Material Copper Alloy
