TVS06RF-19-11P
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
Circular MIL Spec Connector Plug 11P SZ:19 PIN;TRI-START
PDF
/
Buying Options
Total Price: USD $83.08
Unit Price: USD $83.0808
≥1 USD $83.0808
≥10 USD $72.0104
≥100 USD $63.536
≥500 USD $56.848
≥1000 USD $49.852
Inventory: 204
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Contact Material Copper Alloy
Mount Cable, Free Hanging
Mounting Type Free Hanging (In-Line)
Shell Material Aluminum
Insert Material Thermoplastic
Body Material Aluminium
Technical
Operating Temperature -65°C~200°C
Packaging Bulk
Published 2006
Series MIL-DTL-38999 Series III, Tri-Start? TV
Feature Coupling Nut, Self Locking
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
Connector Type Plug, Male Pins
Number of Positions 11
Color Silver
Applications Aviation, Marine, Military
Fastening Type Threaded
Contact Finish - Mating Gold
MIL Conformance YES
DIN Conformance NO
IEC Conformance NO
Filter Feature YES
Mixed Contacts NO
Option GENERAL PURPOSE
Total Number of Contacts 11
Orientation N (Normal)
Shielding Shielded
Ingress Protection Environment Resistant
Military Standard MIL-DTL-38999
Shell Finish Electroless Nickel
Shell Size - Insert 19-11
Contact Gender Male
Empty Shell NO
Backshell Type SOLID
Environmental Characteristics MOISTURE RESISTANT
Plating Electroless Nickel
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Ratings Environment Resistant
