TVS06RF-15-5HB
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
CONN PLUG MALE 5POS GOLD CRIMP
PDF
/
Buying Options
Total Price: USD $72.04
Unit Price: USD $72.038753
≥1 USD $72.038753
≥10 USD $67.961085
≥100 USD $64.114233
≥500 USD $60.48512
≥1000 USD $57.061442
Inventory: 1613
Minimum: 1
-
+
Technical Details
Compliance
Ratings Environment Resistant
RoHS Status ROHS3 Compliant
Dimensions
Contact Finish Thickness - Mating 100.0μin 2.54μm
Technical
Shell Size - Insert 15-5
Shell Finish Electroless Nickel
Reach Compliance Code unknown
Ingress Protection Environment Resistant
Shielding Shielded
Orientation B
Contact Finish - Mating Gold
Fastening Type Threaded
Applications Aviation, Marine, Military
Color Silver
Number of Positions 5
Connector Type Plug, Male Pins
ECCN Code EAR99
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Coupling Nut, Self Locking
Series MIL-DTL-38999 Series III, Tri-Start? TV
Published 2012
Packaging Bulk
Operating Temperature -65°C~200°C
Physical
Insert Material Thermoplastic
Shell Material Aluminum
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 12 Weeks
