TVS06RF-15-19SD image
Favorite
TVS06RF-15-19SD image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Circular Connectors
Description Conn MIL-DTL-38999 Circular SKT 19 POS Crimp ST Cable Mount 19 Terminal 1 Port
PDF
/
Buying Options
Total Price: USD $526.83
Unit Price: USD $526.8296
≥1 USD $526.8296
≥10 USD $460.9792
≥100 USD $409.728
≥500 USD $300.0272
Inventory: 174
Minimum: 1
-
+

Technical Details

Compliance

Ratings Environment Resistant
RoHS Status ROHS3 Compliant
Radiation Hardening No

Dimensions

Contact Finish Thickness - Mating 50.0μin 1.27μm

Technical

Empty Shell YES
Shell Size - Insert 15-19
Shell Finish Electroless Nickel
Ingress Protection Environment Resistant
Shielding Shielded
Orientation D
Total Number of Contacts 19
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Contact Finish - Mating Gold
Fastening Type Threaded
HTS Code 8536.69.40.20
Gender Male
Applications Aviation, Marine, Military
Color Silver
Number of Positions 19
Connector Type Plug, Female Sockets
ECCN Code EAR99
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Coupling Nut, Self Locking
Series MIL-DTL-38999 Series III, Tri-Start? TV
Published 2011
Packaging Bulk
Operating Temperature -65°C~200°C

Physical

Insert Material Thermoplastic
Shell Material Aluminum
Mounting Type Free Hanging (In-Line)
Mount Cable, Free Hanging
Contact Material Copper Alloy

Supply Chain

Factory Lead Time 12 Weeks
