TVS06RF-15-18SD
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
Electroless Nickel MIL-DTL-38999Series III Tri-Start? TV ROHS3Compliant Environment Resistant Circular Connector -65C~200C 50.0muin 1.27mum
PDF
/
Buying Options
Total Price: USD $526.6
Unit Price: USD $526.6008
≥1 USD $526.6008
≥10 USD $460.7768
≥100 USD $409.5784
≥500 USD $293.6032
Inventory: 187
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Contact Material Copper Alloy
Mount Cable, Free Hanging
Mounting Type Free Hanging (In-Line)
Shell Material Aluminum
Insert Material Thermoplastic
Technical
Operating Temperature -65°C~200°C
Packaging Bulk
Published 2006
Series MIL-DTL-38999 Series III, Tri-Start? TV
Feature Coupling Nut, Self Locking
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
ECCN Code EAR99
Connector Type Plug, Female Sockets
Number of Positions 18
Color Silver
Applications Aviation, Marine, Military
Gender Male
HTS Code 8536.69.40.20
Fastening Type Threaded
Contact Finish - Mating Gold
MIL Conformance YES
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Total Number of Contacts 18
Orientation D
Shielding Shielded
Ingress Protection Environment Resistant
Shell Finish Electroless Nickel
Shell Size - Insert 15-18
Empty Shell YES
Plating Electroless Nickel
Dimensions
Length 31.34mm
Contact Finish Thickness - Mating 50.0μin 1.27μm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Ratings Environment Resistant
