TVS06RF-13-4PC image
Favorite
TVS06RF-13-4PC image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Circular Connectors
Description CONN PLUG MALE 4POS GOLD CRIMP
PDF
/
Buying Options
Total Price: USD $523.35
Unit Price: USD $523.3536
≥1 USD $523.3536
≥10 USD $457.9344
≥100 USD $407.1232
≥500 USD $296.1024
Inventory: 77
Minimum: 1
-
+

Technical Details

Compliance

Ratings Environment Resistant
RoHS Status ROHS3 Compliant

Dimensions

Contact Finish Thickness - Mating 50.0μin 1.27μm

Technical

Backshell Type SOLID
Empty Shell YES
Shell Size - Insert 13-4
Shell Finish Electroless Nickel
Reach Compliance Code unknown
Ingress Protection Environment Resistant
Shielding Shielded
Orientation C
Total Number of Contacts 4
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Contact Finish - Mating Gold
Fastening Type Threaded
Gender Male
Applications Aviation, Marine, Military
Color Silver
Number of Positions 4
Connector Type Plug, Male Pins
ECCN Code EAR99
Termination Crimp
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Feature Coupling Nut, Self Locking
Series MIL-DTL-38999 Series III, Tri-Start? TV
Published 2006
Packaging Bulk
Operating Temperature -65°C~200°C

Physical

Insert Material Thermoplastic
Shell Material Aluminum
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material Copper Alloy
