TVPS00RK-17-8S image
Favorite
TVPS00RK-17-8S image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Circular Connectors
Description Conn MIL-DTL-38999 Circular SKT 8 POS Crimp ST Wall Mount 8 Terminal 1 Port
PDF
/
Buying Options
Total Price: USD $567.42
Unit Price: USD $567.4152
≥1 USD $567.4152
≥10 USD $496.4872
≥100 USD $441.32
≥500 USD $319.4928
Inventory: 137
Minimum: 1
-
+

Technical Details

Compliance

Ratings Environment Resistant
RoHS Status ROHS3 Compliant

Dimensions

Contact Finish Thickness - Mating 50.0μin 1.27μm
Length 32.74mm

Technical

Plating Stainless Steel
Environmental Characteristics CORROSION RESISTANT; MOISTURE RESISTANT
Backshell Type SOLID
Empty Shell YES
Shell Size - Insert 17-8
Shell Finish Passivated
Reach Compliance Code unknown
Depth 33.7mm
Ingress Protection Environment Resistant
Shielding Shielded
Orientation N (Normal)
Total Number of Contacts 8
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature YES
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Contact Finish - Mating Gold
Fastening Type Threaded
Gender Female
Applications Aviation, Marine, Military
Number of Positions 8
Connector Type Receptacle, Female Sockets
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Firewall Usage
Series MIL-DTL-38999 Series III, Tri-Start? TV
Published 2006
Packaging Bulk
Operating Temperature -65°C~200°C

Physical

Insert Material Thermoplastic
Shell Material Stainless Steel
Mounting Feature Flange
Mounting Type Panel Mount
Mount Flanges, Panel
Contact Material Copper Alloy

Supply Chain

Factory Lead Time 16 Weeks
