TVP00RF-9-9PC-P25
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
Circular Connector
PDF
/
Inventory: 8699
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Copper Alloy
Contact Plating Gold
Mount Flanges, Panel, Through Hole
Mounting Type Panel Mount, Through Hole
Mounting Feature Flange
Number of Pins 23
Shell Material Aluminum
Technical
Operating Temperature -65°C~175°C
Packaging Bulk
Published 2012
Series MIL-DTL-38999 Series III, Tri-Start? HD
Feature Shielded
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type Receptacle, Male Pins
Number of Positions 9
Max Operating Temperature 175°C
Min Operating Temperature -65°C
Color Silver
Applications Military
Fastening Type Threaded
Contact Finish - Mating Gold
Orientation C
Shielding Shielded
Ingress Protection Environment Resistant
Shell Finish Electroless Nickel
Shell Size - Insert 9-9
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Compliance
RoHS Status ROHS3 Compliant
Ratings Environment Resistant
