TV07DZ-23-151S
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
Circular Connector
PDF
/
Inventory: 2001
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Copper Alloy
Mount Bulkhead, Front Side Nut, Panel
Mounting Type Panel Mount
Mounting Feature Bulkhead - Front Side Nut
Shell Material Aluminum
Technical
Operating Temperature -65°C~175°C
Packaging Bulk
Published 2012
Series MIL-DTL-38999 Series III, Tri-Start? HD
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
Connector Type Receptacle, Female Sockets
Number of Positions 151
Color Black
Applications Military
Fastening Type Threaded
Contact Finish - Mating Gold
Orientation N (Normal)
Shielding Unshielded
Ingress Protection Environment Resistant
Reach Compliance Code unknown
Shell Finish Black Zinc Nickel
Shell Size - Insert 23-151
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Compliance
RoHS Status ROHS3 Compliant
Ratings Environment Resistant
