TV07DZ-15-19JC
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
Black Zinc Nickel MIL-DTL-38999Series III Tri-Start? TV ROHS3Compliant Environment Resistant Circular Connector 175C 100.0muin 2.54mum
PDF
/
Inventory: 7222
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Copper Alloy
Contact Plating Gold
Mount Bulkhead, Front Side Nut, Panel
Mounting Type Panel Mount
Mounting Feature Bulkhead - Front Side Nut
Number of Pins 19
Shell Material Aluminum
Material Aluminium
Insert Material Thermoplastic
Technical
Operating Temperature -65°C~175°C
Packaging Bulk
Published 2013
Series MIL-DTL-38999 Series III, Tri-Start? TV
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
Connector Type Receptacle, Female Sockets
Number of Positions 19
Max Operating Temperature 175°C
Min Operating Temperature -65°C
Color Black
Applications Aviation, Marine, Military
Gender Female
Fastening Type Threaded
Contact Finish - Mating Gold
Orientation C
Shielding Unshielded
Ingress Protection Environment Resistant
Shell Finish Black Zinc Nickel
Shell Size - Insert 15-19
Dimensions
Contact Finish Thickness - Mating 100.0μin 2.54μm
Compliance
RoHS Status ROHS3 Compliant
Ratings Environment Resistant
