TV07DZ-13-8SD
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
CONN RCPT FMALE 8POS GOLD CRIMP
PDF
/
Inventory: 6575
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Contact Material Copper Alloy
Contact Plating Gold
Mount Bulkhead, Front Side Nut, Panel
Mounting Type Panel Mount
Mounting Feature Bulkhead - Front Side Nut
Number of Pins 8
Shell Material Aluminum
Material Aluminium
Insert Material Thermoplastic
Technical
Operating Temperature -65°C~175°C
Packaging Bulk
Published 2012
Series MIL-DTL-38999 Series III, Tri-Start? TV
Feature Shielded
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
Connector Type Receptacle, Female Sockets
Number of Positions 8
Max Operating Temperature 175°C
Min Operating Temperature -65°C
Color Black
Applications Aviation, Marine, Military
Gender Female
Fastening Type Threaded
Contact Finish - Mating Gold
Orientation D
Shielding Unshielded
Ingress Protection Environment Resistant
Shell Finish Black Zinc Nickel
Shell Size - Insert 13-8
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Compliance
RoHS Status ROHS3 Compliant
Ratings Environment Resistant
