TV06RF-15-55P
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
CONN PLUG MALE 55POS GOLD CRIMP
PDF
/
Inventory: 8075
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings Environment Resistant
RoHS Status ROHS3 Compliant
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Technical
Plating Electroless Nickel
Environmental Characteristics ENVIRONMENT/FLUID/MOISTURE RESISTANT
Backshell Type SOLID
Empty Shell YES
Contact Gender Male
Mating Information MULTIPLE MATING PARTS AVAILABLE
Shell Size - Insert 15-55
Shell Finish Electroless Nickel
Military Standard MIL-DTL-38999
Reach Compliance Code unknown
Ingress Protection Environment Resistant
Shielding Shielded
Orientation N (Normal)
Total Number of Contacts 55
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Contact Finish - Mating Gold
Fastening Type Threaded
Applications Military
Color Silver
Number of Positions 55
Connector Type Plug, Male Pins
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Coupling Nut
Series MIL-DTL-38999 Series III, Tri-Start? HD
Published 2012
Packaging Bulk
Operating Temperature -65°C~175°C
Physical
Shell Material Aluminum
Number of Pins 23
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material Copper Alloy
