TV06DZ-25-61P
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
Circular Connector
PDF
/
Buying Options
Total Price: USD $204.69
Unit Price: USD $204.686093
≥1 USD $204.686093
≥10 USD $193.100089
≥100 USD $182.169899
≥500 USD $171.858392
≥1000 USD $162.13056
Inventory: 3900
Minimum: 1
-
+
Technical Details
Physical
Contact Material Copper Alloy
Contact Plating Gold
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Shell Material Aluminum
Insert Material Thermoplastic
Technical
Operating Temperature -65°C~175°C
Packaging Bulk
Published 2014
Series MIL-DTL-38999 Series III, Tri-Start? TV
Feature Coupling Nut, Self Locking
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
Connector Type Plug, Male Pins
Number of Positions 61
Max Operating Temperature 175°C
Min Operating Temperature -65°C
Color Black
Applications Aviation, Marine, Military
Fastening Type Threaded
Contact Finish - Mating Gold
Orientation N (Normal)
Shielding Unshielded
Ingress Protection Environment Resistant
Military Standard MIL-DTL-38999
Shell Finish Black Zinc Nickel
Shell Size - Insert 25-61
Contact Gender Male
Plating Nickel, Zinc
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Compliance
RoHS Status ROHS3 Compliant
Ratings Environment Resistant
