SJT07RT-24-61S
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
Conn Subminiature Cylindrical SKT 61 POS Crimp ST Jam Nut 61 Terminal 1 Port
PDF
/
Inventory: 5784
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Contact Material Copper Alloy
Mount Bulkhead, Front Side Nut, Jam Nut, Panel
Mounting Type Panel Mount
Mounting Feature Bulkhead - Front Side Nut
Shell Material Aluminum
Insert Material Polymer
Technical
Operating Temperature -65°C~150°C
Packaging Bulk
Series MIL-DTL-38999 I & III, VG 96912, SJT
JESD-609 Code e4
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
Connector Type Receptacle, Female Sockets
Number of Positions 61
Applications Aviation, Military
Gender Female
Additional Feature STANDARD: MIL-DTL-38999, POLARIZED
Fastening Type Bayonet Lock
Contact Finish - Mating Gold
MIL Conformance YES
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Total Number of Contacts 61
Orientation N (Normal)
Shielding Unshielded
Ingress Protection Environment Resistant
Depth 52.37mm
Shell Finish Cadmium over Nickel
Shell Size - Insert 24-61
Mating Information MULTIPLE MATING PARTS AVAILABLE
Empty Shell NO
Backshell Type SOLID
Contact Style Socket
Environmental Characteristics ENVIRONMENT/MOISTURE RESISTANT
Plating Cadmium
Dimensions
Length 36.93mm
Contact Finish Thickness - Mating 50.0μin 1.27μm
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
Ratings Environment Resistant
