MS3476L22-55S
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
Circular MIL Spec Connector ST PLUG 55P SZ 20 SOCKET
PDF
/
Buying Options
Total Price: USD $127.03
Unit Price: USD $127.028
≥1 USD $127.028
≥10 USD $116.56568
Inventory: 71
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Contact Material Copper Alloy
Contact Plating Gold
Mount Cable, Free Hanging
Mounting Type Free Hanging (In-Line)
Shell Material Aluminum
Body Material Aluminium
Technical
Operating Temperature -65°C~200°C
Packaging Bulk
Published 2006
Series Military, MIL-DTL-26482 Series II
Feature Coupling Nut, Ground
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
Connector Type Plug, Female Sockets
Number of Positions 55
Max Operating Temperature 200°C
Min Operating Temperature -65°C
Color Silver
Applications Aviation, Industrial, Instrumentation, Marine, Military, Testing Equipment
Gender Male
Voltage - Rated 600V
Fastening Type Bayonet Lock
Contact Finish - Mating Gold
Orientation N (Normal)
Shielding Shielded
Ingress Protection Environment Resistant
Current Rating 7.5A
Military Standard MIL-DTL-26482
Shell Finish Electroless Nickel
Shell Size - Insert 22-55
Number of Contacts 55
Contact Gender Female
Plating Electroless Nickel
Wire Gauge (Max) 24 AWG
Wire Gauge (Min) 20 AWG
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Compliance
Radiation Hardening No
REACH SVHC Unknown
RoHS Status Non-RoHS Compliant
Ratings Environment Resistant, IP67
